Measuring Brand Visibility Across AI Answer Engines

Download LaTeX PDF

Abstract

As AI answer engines replace traditional search for millions of queries, brands face a measurement gap: no predominant methodology exists to quantify whether or why a brand appears in AI-generated responses. We address this with a large-scale empirical study collecting 110,523 responses from four production AI systems — GPT-4.1, Claude Sonnet 4.5, Gemini 2.5 Flash, and Google AI Overviews — across 50 brands (plus 5 fictitious controls) spanning five verticals and three market tiers. Brands and keywords were drawn from top Google organic rankings, providing an upper-bound test of whether traditional search authority transfers to AI visibility.

Our central finding is that keyword–brand alignment is the strongest marginal predictor of brand mention (marginal η² = 32.5%), followed by brand identity (11.2%) and intent type (5.2%); these marginal values overlap and should not be summed. A GLMM confirms the pattern: keyword and brand random effects account for 29.2% and 24.0% of variance respectively, with 46.7% residual. Which AI system answers explains just 0.1% — systems converge on whether to mention a brand but diverge markedly in style (hedging: 2.8%–31.7%; word count: 222–675). Market tier explains 0.3%, providing little support for the assumption that larger brands enjoy higher AI visibility. Two distinct patterns of brand absence emerge: absorption (healthcare content synthesized without attribution; 94.9% of responses where the target brand is absent contain no commercial brand) and displacement (competitors fill default rosters in finance and technology). Citation rates reveal a structural divide: AI Overviews cite brand URLs in 28.7% of responses; standalone LLMs aggregate below 1%. A supplementary web-search extension confirms this is not a retrieval limitation: enabling web search raises GPT-4.1's overall URL rate to 31.0% but brand-specific citations remain below 3% across all LLMs. Data, scoring code, and prompt sets are released for replication.

Keywords: AI answer engines, brand visibility, generative search, AEO, multi-model evaluation, cross-model agreement

1. Introduction

1.1 The Measurement Gap

When a consumer asks ChatGPT "what's the best CRM software?" the answer names specific brands — but which ones, and why? This question has no predominant methodology for answering it. The shift from ranked links to generated prose has created a measurement gap: the brands that built their digital presence on SEO now face an environment where their visibility is shaped by opaque model internals rather than indexable page properties alone.

15–25% of informational queries now trigger AI-generated answers [1]. ChatGPT processes 37.5M queries per day with 59% "fan-out" to other sources [2]. Zero-click searches exceed 65% on mobile [3]. Industry data [4] documents 60%+ CTR reduction for queries with AI Overviews in featured position.

Traditional SEO measurement — rank tracking, SERP features, click-through rates [5, 6] — cannot measure brand presence in generative text. A URL either appears in a ranked list or it does not; but a brand can be mentioned, recommended, compared, hedged against, or absorbed into a synthesis without attribution. Commercial tools (e.g., Profound, Semrush AI Overview tracking) have emerged but publish no scoring methodology, provide no confidence intervals, and are not independently replicable. No academic framework exists for measuring, comparing, or explaining brand visibility across AI systems.

1.2 Research Gaps

GEO [7] introduced optimization but used simulated engines, single models, and temperature=0. CC-GSEO-Bench [8] advanced influence measurement but tested one model. Strauss et al. [9] documented the citation crisis but did not measure brand-level visibility. Characterizing Web Search [10] acknowledged non-determinism but called for repeated sampling rather than measuring it.

To our knowledge, no published academic work: (1) measures visibility across multiple production AI systems simultaneously; (2) validates measurement with fictitious brand controls; (3) quantifies how much variance in visibility is explained by each factor; (4) identifies the mechanisms of brand invisibility.

1.3 Hypotheses

We formulated five hypotheses from the literature and tested each with a pre-specified methodology. Table 1 summarizes all hypotheses and their verdicts. This structure allows honest reporting of both confirmations and surprises. Measurement integrity is established separately via fictitious brand controls (§4.1).

Table 1: Hypotheses with literature basis and empirical verdicts.

1.4 Contributions

We make six specific claims:

1. Multi-model empirical measurement at scale — 110,523 responses across 4 production AI systems, 5 verticals, 3 tiers, and 5 intent types, with open scoring code and prompt sets.
2. Construct validation via fictitious brand controls — 5 invented brands establish a verified 0% measurement floor.
3. Marginal association analysis of visibility predictors — keyword–brand alignment is the strongest marginal predictor (marginal η² = 32.5%); model choice explains 0.1%, and tier 0.3%, providing little support for brand-size assumptions. (Marginal values overlap due to hierarchical nesting; see §3.5.)
4. Two patterns of brand absence: absorption and displacement — in YMYL domains, content is synthesized without attribution (~95% of healthcare responses where the target brand is absent contain no commercial brand); in competitive domains, absent brands are displaced by competitors.
5. Cross-model agreement analysis — models agree on brand absence in 76.2% of prompts but on presence in only 9.4% (Fleiss' κ = 0.647, substantial agreement), making multi-model measurement essential.
6. Brand mention shows high consistency at temperature=1.0 in limited repeats — ~95% of keyword–source pairs yield identical results across 4–5 repeated prompts (Claude 94.9%, GPT-4.1 96.2%), though the small number of repeats limits power to detect low-probability stochastic variation.

2. Related Work

2.1 Generative Engine Optimization

GEO [7] introduced the field with 10K queries across 9 domains, finding a stable generative engine. Two visibility metrics were proposed: Position-Adjusted Word Count (citation-centric) and Subjective Impression (LLM-evaluated). Statistics Addition and Quotation Addition improved visibility (+28–41%), while Keyword Stuffing performed worse than baseline. Key limitations: simulated engine, single model, no non-determinism treatment.

CC-GSEO-Bench [8] advanced the field with 1,000+ source articles and 5,000+ query-article pairs, measuring three influence dimensions: Exposure, Faithful Credit, and Causal Impact. Strategy effectiveness was shown to be context-dependent. Limitation: single model (gpt-4.1-mini).

E-GEO [16] extended GEO to e-commerce with 7K+ product queries, finding a stable, domain-agnostic optimization pattern. GEO-16 [15] proposed a 16-pillar auditing framework across 70 prompts with 1,702 citations. White Hat SEO [17] and RAID G-SEO [18] explored LLM-aware content optimization strategies, though both focused on single-model settings.

Table 2 summarizes key differences between our study and prior work.

Table 2: Comparison with prior generative search studies.

‡ 56,803 baseline (2 snapshots) + 53,720 web-search-enabled (3 snapshots)

2.2 The Attribution Crisis

Strauss et al. [9] analyzed ~14,000 LMArena conversation logs, finding 34% of Gemini responses generated without fetching online content and 92% lacking citations. Citation efficiency ranged from 0.19 to 0.45 per relevant page visited. Our LLM citation rate (<1% for Claude, Gemini; 2.3% for GPT-4.1) confirms this for standalone models, while AIO's 28.7% citation rate reveals that search-grounded systems exhibit markedly higher citation rates.

Venkit et al. [14] identified 16 limitations in AI search engines through a 21-participant user study, including hallucination, misattribution, and overconfident language. Citation Alignment [19] showed LLMs are 27% more likely than humans to cite Wikipedia-flagged text. Khalifa et al. [12] demonstrated that attribution behavior is trainable and architecturally dependent.

2.3 Adversarial Manipulation

Pfrommer et al. [11] (EMNLP '24) demonstrated that different LLMs vary significantly in weighting product name vs. document content vs. context position — direct support for model-specificity in cross-model measurement.

2.4 Behavioral Testing of NLP Models

Ribeiro et al. [20] introduced CheckList, a task-agnostic behavioral testing methodology that decomposes model evaluation into capability-specific test types (Minimum Functionality, Invariance, Directional Expectation). Our prompt design adapts this framework: intent-type variations test directional expectations (recommendation prompts should surface more brands than informational ones), control repeats test minimum functionality, and paraphrase sets test invariance. Shin et al. [21] showed that prompt phrasing significantly affects knowledge elicitation, motivating our 10-variation-per-keyword design to capture phrasing sensitivity.

2.5 Traditional Search Measurement

Feuerriegel et al. [5] established the SEO measurement gold standard with 67,000 keywords and 6M clicks. Huszár et al. [22] introduced the "performativity gap" concept with bootstrap confidence intervals. Rise of AI Search [23] analyzed 2.8M search results, finding lower response variety and citation concentration in AI search. PageRank [17] and Learning to Rank [24] established SEO foundations; no equivalent exists for LLMs.

3. Methodology

3.1 Brand Selection and Stratification

We selected 50 brands across five verticals using five criteria: (1) consumer searchability, (2) content presence, (3) tier stratification defensible by market position, (4) within-vertical competition, and (5) cross-vertical diversity. Table 3 shows the full corpus.

SEO-informed selection. Brands were selected from those ranking in the top positions of Google organic search results, using Ahrefs data to identify brands with strong organic visibility across relevant category keywords. This design is intentional: by studying brands that have already "won" in traditional search ranking, we test whether organic search authority transfers to AI answer engine visibility — or whether LLMs operate on fundamentally different selection criteria.

†Healthcare has 2 midmarket and 4 startup brands due to the vertical's market structure; all other verticals follow the 4/3/3 split.

Five fictitious brands (one per vertical) were verified non-existent via web search on 2026-02-27. They share keyword sets with real counterparts; any detection constitutes a scoring error.

Table 3: Brand corpus: 50 brands + 5 fictitious controls across 5 verticals and 3 tiers.

3.2 Keyword and Prompt Design

Pipeline. Human-curated keywords → LLM-generated prompts (GPT-4o-mini) → human review → approved prompts.

Scale. 750 keywords, 10,508 prompts (7,508 variations + 3,000 controls for real brands; 3,060 total controls including fictitious). Each keyword receives up to 10 prompt variations spanning 5 intent types plus 4 control repeats of an identical seed prompt (14 per keyword). This design follows CheckList's [20] behavioral testing taxonomy: intent variations test directional expectations, controls test minimum functionality, and paraphrase sets test invariance.

Critical constraint. Prompts never mention the target brand, validated automatically via substring matching against brand names and aliases.

Dual-format strategy. Conversational prompts for API models; search-native variants for AIO, reflecting documented query-length differences (Google ~3.4 words vs. ChatGPT ~23 words [25]). A format-consistent subset (search-format prompts only, excluding conversational variants) is available in supplementary materials as a robustness check.

Statistical note. The 10 variations per keyword are correlated paraphrases, not independent samples. Effective N = 750 keywords for headline statistics.

Keyword composition. Keywords were sourced from Ahrefs organic keyword data for each brand — the same queries where these brands rank highly in Google organic search. This creates a deliberate research design: every keyword–brand pair represents a query where the brand has demonstrated organic search authority. If SEO ranking transferred directly to LLM visibility, we would expect high mention rates across the board. Instead, the 85% average absence rate demonstrates that organic search authority alone does not guarantee AI visibility (though this is a restricted-range test; see §5.2). Keywords include category queries ("best CRM software"), topic queries ("simparica"), and navigational queries ("pay in 4"). Only 3 of 750 contain the target brand name explicitly. The set is overwhelmingly unbranded.

3.3 Data Collection Architecture

Figure 1 shows the collection pipeline. API models (GPT-4.1, Claude Sonnet 4.5, Gemini 2.5 Flash) are queried via LiteLLM at temperature=1.0 using each provider's native API. Web search and retrieval tools are explicitly disabled for all three LLM sources; responses reflect only what is encoded in each model's training data, with no live web grounding. All three LLM sources use an identical system prompt ("Answer the user's question directly and helpfully.") to standardize instruction context. Google AI Overviews are collected via SerpAPI with geolocation pinned to Chicago, IL, and are search-grounded by design — making AIO the only real-time retrieval source in the baseline study. To test whether web access closes the citation gap, a supplementary extension re-queries the same three LLMs with web search tools enabled (n=53,720 responses; §5.1).

We collected 56,803 baseline responses across two snapshots (snapshot 7: 2026-02-28; snapshot 8: 2026-03-07). Of these, 52,998 have non-null text and form the primary analysis dataset: 18,264 scored AIO responses, 11,817 from Claude Sonnet, 11,101 from GPT-4.1, and 11,816 from Gemini Flash. Results were consistent across both snapshots (overall mention rate: 17.9% vs. 17.3%), providing limited temporal validation of the baseline findings.

Figure 1: Data collection and scoring architecture.

Three LLM APIs and Google AI Overviews feed into a shared response store scored with a 23-metric programmatic pipeline.

            ┌──────────────────────────────┐
            │  Scheduler (cron / manual)   │
            └──────────────┬───────────────┘
                           │
             ┌─────────────┴─────────────┐
             ▼                           ▼
    ┌──────────────────┐       ┌──────────────────┐
    │  API Dispatcher  │       │   AIO Collector  │
    │     LiteLLM      │       │      SerpAPI     │
    └────────┬─────────┘       └─────────┬────────┘
             │                           │
             └─────────────┬─────────────┘
                           ▼
            ┌──────────────────────────────┐
            │  MySQL — 110,523 responses   │
            └──────────────┬───────────────┘
                           ▼
            ┌──────────────────────────────┐
            │ Scoring Pipeline — 23 metrics│
            │         8 categories         │
            └──────────────┬───────────────┘
                           ▼
            ┌──────────────────────────────┐
            │      Export / Analysis       │
            └──────────────────────────────┘

3.4 Scoring Approach

We use programmatic scoring across 8 signal categories (23 metrics total; see Appendix B): word-boundary regex for brand mention detection, domain matching for URL citations, list-position parsing for recommendation rank, phrase-list matching for hedging/disclaimer language, VADER for sentiment, and spaCy [26] NER for entity discovery. This captures surface signals reliably but does not capture semantic influence, prominence nuance, or context-aware sentiment.

Known limitations. (1) VADER misses domain-specific sentiment. (2) Phrase lists are hand-curated (Appendix B). (3) Sentiment is confounded with keyword topic valence. (4) Brand mention detection uses canonical names and configured aliases; common shorthand forms (e.g., "Schwab" for Charles Schwab, "CVS" for CVS Health) are detected only where aliases are configured, potentially undercounting mentions for brands with well-known abbreviations. (5) Fictitious brand controls validate the false positive floor (0/356) but do not quantify false negatives or precision for ambiguous brand names (e.g., Linear, Bolt, Mercury, Ro are common English words). A human-labeled validation sample is identified as future work.

3.5 Statistical Approach

Two-level analysis. Level 1: keyword-level aggregation (N=750) with Wilson 95% CIs for proportions (Appendix C). Level 2: phrasing sensitivity (within-keyword SD of mention scores).

Control prompts. 4 repeats of identical seed prompts per keyword (3,060 control prompts) provide a stochastic variance baseline.

Marginal association analysis. Marginal η² (one-way ANOVA per factor) quantifies how much variance in brand_mentioned each factor explains independently. Because factors are hierarchically nested — keyword within brand, brand within vertical, tier as a property of brand — these are marginal contributions that overlap, not an additive partition. We report them for descriptive ranking, not as unique variance claims.

Statistical tests. Chi-square with Cramér's V for categorical comparisons; Fisher's exact where expected cells < 5; Bonferroni correction for multiple comparisons; Cohen's h for pairwise proportion effects.

3.6 Limitations (Upfront)

• Temporal scope: Two baseline snapshots (snapshot 7: 2026-02-28; snapshot 8: 2026-03-07) plus three web-search snapshots; temporal stability partially validated.
• Single sample per prompt variation. CIs from within-keyword aggregation.
• Programmatic scoring only. Primary signal is binary brand mention.
• English-language only.
• Sentiment confound: VADER + keyword topic valence.
• Keyword composition: Includes topic/entity queries with weak brand alignment (e.g., "simparica" for Chewy). This inflates the 0% floor but reflects real-world search behavior (see §4.4).
• No causal claims. Observational study throughout.

4. Results

We begin with construct validation (§4.1) to establish measurement integrity, then the control-prompt consistency finding (§4.2) that informs a methodological question. The marginal association analysis (§4.3) provides the organizing framework: keyword–brand alignment (32.5%) > brand identity (11.2%) > intent type (5.2%) > vertical (1.7%) > tier (0.3%) ≈ source (0.1%); these marginal η² values overlap due to hierarchical nesting and should not be summed. A GLMM confirms the qualitative ordering: keyword (ICC = 34.4%) and brand (ICC = 23.0%) random effects dominate, with 42.6% residual. Subsequent sections unpack each factor.

Across 52,998 scored responses (variations and controls), the average brand mention rate is 17.6%. The baseline is absence: across ~82% of keyword–brand–source observations — for keywords where these brands rank in top Google organic positions — AI systems do not mention the target brand.

4.1 Construct Validation

Before interpreting real brand results, we must establish that our scoring pipeline does not hallucinate mentions. Five fictitious brands — Wynthoral Financial, Grelvant Law, Plorantic Health, Jorvelle, and Velnith Market — were assigned the same keyword sets as their real vertical counterparts and scored identically. Across 356 scored responses (spanning all sources and intent types), the pipeline detected exactly 0 mentions. No false positives (Wilson 95% CI: [0%, 1.0%]). This validates both the measurement floor and the regex-based detection methodology: all non-zero scores reported below represent genuine brand presence in model outputs.

4.2 Brand Mention Shows High Consistency

A methodological question precedes all results: is brand mention stochastic? GEO [7] assumed yes and set temperature=0 to suppress it. Characterizing Web Search [10] recommended repeated sampling to quantify it. We answer empirically with control prompts — identical text repeated 4–5 times per keyword at temperature=1.0.

Brand mention is highly consistent: Claude (94.9%) and GPT-4.1 (96.2%) produce identical mention outcomes across all control repeats per keyword at temperature=1.0. Across all keyword–source pairs, 78% are always-absent and 11% always-present, with the remainder showing mixed outcomes. The brand-mention decision is consistent with a stable underlying propensity rather than stochastic sampling variation. (With only 4–5 repeats, power to detect a 10% stochastic mention probability is limited; true inconsistency rates may be higher with more repeats.)

Prompt variations show 38.5% mixed results (Claude) vs. 11.0% for controls — a 3.5× higher rate. Phrasing variation is associated with 3.5× more inconsistency than identical-prompt controls. The 11% inconsistency cases mark the optimization frontier: brands at the mention/no-mention decision boundary.

Healthcare shows the least phrasing sensitivity (23.5% mixed vs. 43.2% for e-commerce), consistent with a visibility ceiling for healthcare brands that is robust to prompt phrasing.

4.3 Keyword–Brand Alignment Is the Strongest Marginal Predictor

Table 5 presents the central quantitative finding. Keyword–brand alignment has the largest marginal η² (32.5%) among factors tested. Because keyword identity has 737 levels (vs. 50 for brand, 5 for vertical, etc.), its high marginal η² partly reflects granularity — a categorical variable with many levels will mechanically capture more between-group variance. The finding should be interpreted as: which specific keyword was queried is more informative about brand mention than any other single factor, though a continuous semantic alignment measure (e.g., embedding similarity between keyword and brand) would provide a stronger operationalization. Marginal values overlap due to hierarchical nesting and cannot be summed (see Appendix C).

Table 5: Marginal association strength (marginal η²). Values overlap due to hierarchical nesting and should not be summed.

† 737 of 750 keywords with n ≥ 10 scored responses.

Keywords with 100% mention rate are category-defining queries: "best CRM software" (Salesforce), "best note-taking app" (Notion), "pay in 4" (PayPal). Keywords with 0% rate (262 of 737 with n ≥ 10) are topic/entity queries with weak brand alignment: "simparica" (Chewy), "vitamin d3" (Amazon), "cat noises" (Chewy).

Keyword length. Short keywords (1–2 words): 17.4% mention rate; medium (3–4): 17.3%; long (5+): 11.0%.

Keyword semantic type. Commercial keywords ("best", "compare", "software"): 17.3%. How-to/informational ("how to", "symptoms"): 11.7%. The strongest signal is keyword–brand alignment as an interaction, not a keyword property alone.

Practical implication. Keyword–brand alignment has a far larger marginal η² than AI system choice (32.5% vs. 0.1%). While these marginal values overlap and cannot be directly compared as unique contributions, the qualitative ordering is robust across specifications: AEO strategy should be keyword-first, not model-first.

4.4 Keyword–Brand Alignment: Case Studies

The distribution is bimodal: 35% of keywords (262/737) produce zero brand mentions, while 11% (82/737) exceed 50%. This bimodality, combined with keyword identity having the largest ICC among all factors in the supplementary GLMM (Appendix C), supports treating keyword identity as the primary unit of analysis.

ThredUp (49.0% mention rate) illustrates the pattern (Table 6). Seven of its 15 keywords are variations of "online thrifting" — all above 50% mention rate. ThredUp is the category for online secondhand clothing; its visibility reflects keyword–brand alignment, not brand strength.

Amazon (16.7% overall) is visible only for Amazon-specific products (Kindle, KDP, Prime Video) but invisible for generic product queries. A brand with broad product coverage but no category-defining language achieves low mention rates across queries. This pattern generalizes: Zocdoc (53.4%) owns "find a doctor" while WebMD (0%) is absorbed into general medical knowledge; Vanguard (32.4%) owns "index fund" while Fidelity (15.1%) is a generic brokerage.

Table 6: ThredUp vs. Amazon: keyword-level visibility.

4.5 The Vertical Gradient and Two Absence Patterns [H4]

H4 directional support. Chi-square: p < 10⁻¹²⁷; Cramér's V = 0.120 (small effect) (Table 7). The direction is consistent with H4, but the primary finding is the qualitative distinction between absorption and displacement patterns rather than the magnitude of the vertical gap. Important caveat applied throughout: All chi-square p-values are computed at the response level (N=41,388) and are anti-conservative because the 10 prompt variations per keyword are correlated paraphrases (effective N ≈ 750 keywords). We report p-values for completeness but rely on effect sizes (V, Cohen's h) for interpretation. Keyword-level tests yield qualitatively identical conclusions (see Appendix C).

Table 7: Vertical visibility and caution profile.

The pattern differs by vertical. We identify two distinct patterns of brand absence:

Pattern 1: Absorption (Healthcare). When WebMD is absent (100% of its keyword responses), 94.9% of those responses contain no commercial brand at all. Outputs contain equivalent medical information — symptoms, treatments, drug interactions — referencing institutions (NIH, PubMed) rather than commercial brands. Healthcare has the most 0%-mention keywords (81, highest of any vertical).

Pattern 2: Displacement (Finance, Technology). When finance or tech brands are absent, competitors take their place. Co-occurrence analysis reveals stable "default rosters" (Table 8):

Table 8: AI default rosters by vertical.

Top co-occurring pairs: LegalZoom + Rocket Lawyer (422), Asana + Monday.com (380), HubSpot + Salesforce (295). AIO trigger rates are uniform across verticals (91–95%); the gradient is in answer content, not suppression.

4.6 Cross-Model Agreement and Behavioral Profiles [H1]

Across 5,891 prompts where all 3 LLMs responded (Table 9):

Table 9: Cross-model agreement on brand mention (5,891 three-way prompts).

For context, under independence at the observed ~18% base mention rate, chance three-way absence agreement would be (0.82)³ = 55.1% and chance three-way presence agreement (0.18)³ = 0.58%. The observed 76.2% absence agreement is above chance, and the 9.4% presence agreement is 16× the chance expectation — models converge on brand inclusion far more than independence would predict. Fleiss' κ = 0.647 [0.626, 0.668] indicates substantial agreement per Landis & Koch benchmarks, though κ is sensitive to marginal distributions and the high base rate of brand absence (82%) contributes to this rating. The asymmetry is consistent with the marginal association analysis: source explains only 0.1% of whether a brand appears, but systems diverge on which brands to surface in the 18% of cases where brands appear. Pairwise Cohen's κ ranges 0.67–0.68 between LLMs; no model has a distinctly higher rate of exclusive mentions.

Healthcare and law show highest absence consensus (~87%) and lowest presence consensus (5–7%). Comparative queries produce the most presence agreement (21.7%); informational queries the most absence agreement (90.7%).

H1: Mention rates (not supported). Mention rates cluster narrowly (16.0%–19.3%), with source explaining just 0.1% of variance. However, behavioral profiles diverge markedly: hedging rates span 2.8%–31.7% and word counts span 222–675 across sources (Table 4).

Table 4: Behavioral profiles by source.

AIO is most commercially oriented (highest sentiment, least hedging). Claude is most neutral (lowest sentiment). Gemini is most cautious (highest hedging, 3× Claude's word count). Within-Google divergence (Gemini vs. AIO) is consistent with deliberate product differentiation.

The Citation Divide [H2]. URL citation rates vary dramatically by source type: AIO cites brand URLs in 28.7% of responses (leveraging search-index grounding), GPT-4.1 in 2.3%, while Claude (0.08%) and Gemini (0.10%) produce near-zero citations. H2 partially confirmed for LLMs, rejected for AIO. The LLM-only citation rate is 0.81% — citation-based measurement fails for standalone LLMs but works for search-grounded systems. A preliminary web-search extension (n=53,720; §5.1) confirms this is not merely a retrieval limitation: with web search enabled, GPT-4.1's overall URL rate rises to 31.0% but brand-specific citations remain flat at 2.4%, and aggregate brand URL citation across all three web-search LLMs stays below 3%.

4.7 Market Tier Does Not Predict Visibility [H3]

H3 not supported. While statistically significant (χ²: p < 10⁻⁵³), the effect size is negligible (Cramér's V = 0.067); tier explains 0.3% of variance (Table 10).

Table 10: Mention rate by tier × vertical.

Only technology follows the expected hierarchy. Stratifying by keyword–brand alignment explains the pattern: high-alignment keywords (>25% mention rate) yield ~50% mention regardless of tier (enterprise 52.0%, midmarket 47.4%, startup 49.1%), while low-alignment keywords cluster at 4–6% across all tiers. The apparent tier effect is largely explained by differences in keyword–brand alignment density across tiers — startups with strong category alignment (ThredUp = online thrifting) outperform enterprise brands with diffuse associations (Amazon = everything).

Domain authority as a continuous signal. To probe whether the null tier result masks a genuine authority effect, we supplemented the categorical analysis with continuous Ahrefs Domain Rating (DR) scores for all 50 brand domains (retrieved 2026-03-01, range DR 57–96). Across all brands and LLM sources, Spearman ρ = +0.34 (p = 0.017) — weak but significant; AI Overviews shows negligible association (ρ = +0.17, ns), consistent with retrieval-based rather than parametric selection.

Stratifying by tier reveals a ceiling effect that explains the aggregate. Enterprise brands occupy a compressed DR band (73–96, σ = 5.8), leaving too little variance for the signal to surface (ρ = +0.28, ns; n = 20). Midmarket shows near-zero correlation (ρ = +0.06, ns; n = 14) for the same reason. Within startups, however, where DR ranges from 57 to 92 (σ = 8.3), domain authority is strongly predictive of mention rate (ρ = +0.82, p < 0.001, n = 16; leave-one-out range 0.80–0.90). The startup correlation partly reflects this tier's wider DR range. The aggregate weak result is a restricted-range artifact: by selecting brands that have already "won" traditional search, our corpus suppresses the variation needed to detect a monotonic DR effect.

Counter-examples suggest a threshold rather than monotonic interpretation. Using LLM-only mention rates (excluding AIO, which is retrieval-augmented): WebMD (DR = 92, 0%), Mayo Clinic (DR = 93, 0.6%), and Nolo (DR = 73, 5.9%) — all from YMYL verticals where absorption depresses mention rates (confounding with H4) — demonstrate that high domain authority does not ensure LLM visibility when keyword–brand alignment is absent. Conversely, Notion (DR = 92, 75% mention) shows that a startup-tier domain can dominate when its content is semantically entangled with query categories in training data. The data suggest a sufficiency threshold in the DR 70–80 range (mention rates rise from ~5% below to ~15–20% above), though within-bin variance is large and formal changepoint analysis on 50 brands is underpowered; above this range, keyword–brand alignment becomes the decisive factor.

Competitor comparison. The alignment effect is further visible in competitor analysis: target brands (those ranking in Google's top 5 for a keyword) are mentioned at 17.4% by LLMs, 6× higher than same-vertical competitors (2.92%) and far above other-vertical brands (0.19%; n=18,039 LLM responses with non-null text). Within the top 5, however, exact rank position shows no linear association with LLM mention rate (ρ = +0.04, ns; coded 1=best), though AIO exhibits modest rank-sensitivity (ρ = −0.103, p = 0.007).

4.8 Intent Type and Position Dynamics [H5]

H5 confirmed. χ²: p < 10⁻²⁸³; Cramér's V = 0.231 — the largest Cramér's V in the study (Table 11).

Table 11: Mention rate by intent type.

The ranking is model-independent: comparative > constrained > recommendation > problem-solving > informational across all 4 sources, with a 4× gap between the highest and lowest intent types.

Position dynamics. When brands appear in ranked lists, position is cross-model stable. ThredUp holds #1 across all 4 sources in e-commerce; Ro holds #1 in healthcare; LegalZoom #1 in law. Position analysis carries an important caveat: brands mentioned in low-visibility verticals are a highly selected sample. Ro's 47.3% share-of-response reflects the bimodal nature of YMYL brand presence — almost always absent, but prominent when present.

Selection bias in position data. Position rank varies by intent: constrained queries yield the best average rank (5.12) despite lower mention rates (22.6%), while comparative queries produce more mentions (26.9%) at worse average positions (7.42). By tier, startups achieve rank #1 most often (32.6% of ranked mentions vs. 20.8% enterprise, 17.4% midmarket) — likely because startup mentions occur in narrower, more definitive contexts. These position statistics condition on brand appearance, a highly selected subset; they should not be interpreted as unconditional rankings.

5. Discussion

We discuss five implications of the findings above.

5.1 The Citation Divide

Citation behavior reveals a large gap between system types. AIO cites brand URLs in 28.7% of responses; standalone LLMs cite at far lower rates (GPT-4.1: 2.3%, Claude: 0.08%, Gemini: 0.10%). This renders citation-based measurement — including GEO's Position-Adjusted Word Count — ineffective for brand-grounded systems but highly informative for search-grounded systems. The implication for practitioners: AIO is not just the most brand-friendly surface for mentions, but also the only one that provides verifiable attribution. Khalifa et al. [12] show citation is technically fixable in LLMs but commercially unmotivated.

Web-search extension. To test whether enabling web search tools closes the citation gap, we collected 53,720 additional responses from the same three LLMs with web search enabled across 3 web-search snapshots (Table 12).

Table 12: Brand URL citation rates: baseline vs. web-search-enabled LLMs (n=53,720).

While GPT-4.1's overall URL citation rate rises sharply (2.3% → 31.0%), brand-specific URL citations remained flat at 2.4%. Claude and Gemini brand citations stayed near zero. LLMs with web-search cite generic URLs but still do not attribute to brand domains.

5.2 The Keyword–Brand Alignment Thesis

The marginal association analysis is our central empirical result. Keyword–brand alignment has marginal η² = 32.5%, source 0.1%, tier 0.3%; a supplementary GLMM confirms the qualitative ordering (Appendix C). AI visibility is most strongly associated with how well a brand maps to the query's semantic category, not which AI system is queried or how large the brand is.

The ThredUp/Amazon case (§4.4) illustrates the pattern: ThredUp is the category for "online thrifting"; Amazon lacks a single defining category. The Zocdoc/WebMD case shows a similar pattern: specific transactional content ("book a doctor") is associated with higher mention rates than encyclopedic content ("symptoms of diabetes"), plausibly because the former requires naming a service while the latter can be synthesized from parametric knowledge.

This thesis is testable through content attribute analysis (Paper 2): brands with dense, recommendation-oriented, category-defining language should outperform those with broader content, controlling for domain authority and traffic.

SEO authority is insufficient. Our brands were drawn from Google's top organic rankings — they have already "won" traditional search. Yet the transfer to LLM visibility is strikingly incomplete (Table 13). Target brands that rank in Google's top 5 are mentioned at 17.4% by LLMs — 6× more than same-vertical competitors (2.92%) and 92× more than brands from other verticals (0.19%). There is a strong association between organic ranking and LLM mention, but the direction of causation is ambiguous: ranking may influence mention (via training data or retrieval), or keyword–brand semantic alignment may independently drive both rank and mention — the marginal association analysis (keyword–brand alignment marginal η²=32.5%) is consistent with either account.

Critically, position within the top 5 does not differentiate: rank #1 and ranks #2–5 yield statistically indistinguishable LLM mention rates (ρ = +0.04, ns). AIO shows a modest rank-#1 advantage (ρ = −0.103, p = 0.007), plausibly reflecting shared Google infrastructure. Nearly half of all keywords (48.2%) receive zero LLM mentions despite top-5 organic ranking, and only one-third (32.7%) achieve mention from all three LLMs (Table 13). This is a restricted-range finding: we cannot claim SEO signals are irrelevant to LLM visibility in general, only that within brands that already rank highly, additional organic authority yields diminishing returns.

Table 13: Transfer from Google organic rank to LLM visibility. All 737 keywords have the target brand in Google's top 5 organic results.

5.3 Absorption vs. Displacement

Brand absence exhibits different patterns depending on vertical:

Absorption is the pattern where AI outputs contain equivalent information to authoritative brand content but without attribution. This pattern is consistent with an unintended consequence of producing authoritative content under E-E-A-T [27]: such content may appear in AI outputs without attribution, consistent with parametric knowledge synthesis. WebMD's medical content, Mayo Clinic's guidelines — the information appears but the brand names do not. When these brands are absent, 94.9% of responses contain no commercial brand at all, with outputs referencing institutional sources (NIH, PubMed, CDC) as detected via entity discovery [26].

Displacement occurs when competitors appear instead. In finance and technology, the default roster redistributes attention — a zero-sum dynamic.

These patterns have different strategic implications. Brands exhibiting the absorption pattern would benefit from content so specific and transactional that the brand name becomes part of the answer. Brands exhibiting displacement would benefit from entering the default roster through recommendation-context content.

5.4 AIO as Most Commercial Surface

AIO is the most commercially oriented surface across every metric: highest mention rate (19.3%), highest sentiment (0.345 compound), lowest hedging (2.8%), and lowest disclaimer rate (3.2%). One possible explanation is that AIO inherits ranking signals from its underlying search index, which is optimized for commercial relevance; alternative explanations include differences in retrieval-augmented generation or fine-tuning objectives.

The within-Google divergence is notable. Gemini Flash, sharing the same corporate parent, produces 11× more hedging, 4× more disclaimers, and 2.7× longer responses (675 vs. 251 avg words). Despite shared corporate parentage, the two systems produce markedly different behavioral profiles (whether they share training data is unknown). This is consistent with different design objectives: AIO may be tuned for commercial utility while Gemini may be tuned for conversational caution, though the exact tuning objectives are not publicly documented.

Yet the 0.1% source variance warns against overindexing on any single surface. The brand-mention decision is overwhelmingly predicted by the query (keyword) and the target (brand), not which AI system is queried.

5.5 The Vertical Gradient and Fairness

Although the effect size is small (V = 0.120), the 2.0× gap (Healthcare 12.1% vs. Finance 24.0%) raises a fairness question that Venkit et al. [14] anticipated: AI systems may exhibit systematically different competitive landscapes across verticals. Healthcare brands face a structural ceiling that is cross-model (86.9% unanimous absence), phrasing-robust (23.5% sensitivity), and brand-free by default. A healthcare startup investing in AEO faces fundamentally different odds than a fintech startup — not solely because of market dynamics, but plausibly because of structural factors in how AI systems handle medical content — though the specific mechanism (alignment training, safety tuning, or other factors) is not identifiable from observational data.

The absorption pattern is consistent with much of this. AIO trigger rates are uniform across verticals (91–95%), so the gap is in answer content, not in whether AI answers appear. Models are equally willing to generate AI answers for healthcare queries — they are simply less willing to name commercial brands in those answers. This is arguably good for consumers (fewer conflicts of interest in medical advice) but creates an uneven competitive landscape that brands cannot overcome through content strategy alone.

5.6 Limitations

Temporal scope: two baseline snapshots (2026-02-28 and 2026-03-07) with limited temporal validation; plus three web-search snapshots. Programmatic scoring only: binary brand mention is the primary signal; LLM-as-judge scoring would add nuance. Gemini coverage: 5,847 scored responses (99.98% of collection); cross-model agreement uses 5,891 three-way LLM prompts (Fleiss' κ = 0.647). Keyword composition: topic/entity queries inflate the 0% floor and drive the keyword-dominance finding; a different keyword set would shift variance ratios. Marginal association analysis: marginal η² values overlap due to hierarchical nesting and differences in factor granularity (737 keyword levels vs. 5 for vertical). A supplementary GLMM (BinomialBayesMixedGLM) confirms the qualitative ordering: keyword ICC = 34.4%, brand ICC = 23.0%, residual = 42.6%, with intent type as the strongest fixed effect (V = 0.231). Restricted-range DR: brands were selected from top Google organic rankings (DR 57–96); the weak DR correlation cannot generalize to brands with low domain authority. Mechanism ambiguity: all findings are correlational, not causal.

6. Conclusion

We measured brand visibility across 4 production AI answer engines — 110,523 responses (56,803 baseline; 53,720 web-search-enabled) from 50 brands across 5 verticals. Of five hypotheses (Table 1), one was supported (H5: intent V = 0.231), one received directional support (H4: YMYL 2.0× lower, V = 0.120; the absorption/displacement distinction is the primary contribution), one partially confirmed (H2: LLM aggregate citation rate 0.81% vs. AIO 28.7%; even with web search enabled, brand URL citation remains <3% across LLMs), and two were not supported in practice (H1: source explains 0.1% of variance; H3: tier V = 0.067, though continuous DR predicts mention within startups at ρ = +0.82). Measurement integrity was established separately: fictitious brand controls yielded 0/356 mentions with no false positives (§4.1).

The marginal association hierarchy: keyword–brand alignment (32.5%) > brand identity (11.2%) > intent type (5.2%) > vertical (1.7%) > tier (0.3%) ≈ source (0.1%); these marginal η² values overlap and should not be summed. AEO strategy should be keyword-first, not model-first. Two patterns of brand absence — absorption (YMYL) and displacement (competitive) — suggest different content strategies. Brand mention is ~95% consistent at temperature=1.0 in limited repeats. Among brands that already dominate Google rankings, organic search authority adds little incremental LLM visibility — the average mention rate is only 17.6% despite uniformly high domain authority. Cross-model measurement is essential: 76.2% absence consensus vs. 9.4% presence consensus (Fleiss' κ = 0.647).

Despite limitations in temporal scope, scoring depth, and causal inference, the methodology is fully open and the findings are replicable. For practitioners: optimize for keyword–brand alignment, not model-specific tactics; measure across multiple AI systems, not just one; and recognize that YMYL domains face structurally lower visibility ceilings. Priority extensions include temporal snapshots for stability testing, LLM-as-judge scoring to quantify absorption depth, human-labeled validation of scoring precision for ambiguous brand names, a continuous keyword–brand semantic alignment measure (preliminary embedding analysis yields Spearman ρ = 0.42, p < 10⁻³², ΔR² = 0.065 beyond fixed effects), and the content attribute analysis of Paper 2. By providing open data, validated methodology, and falsifiable claims, this study establishes an initial empirical foundation for AI answer engine measurement.

References

1. Advanced Web Ranking. AI Overview Trigger Rates and CTR Impact. Industry Report, 2025.
2. Nectiv. ChatGPT Query Volume and Fan-Out Analysis. Industry Report, 2025.
3. SparkToro/Datos. Zero-Click Search Trends. Industry Report, 2025.
4. Ahrefs. AI Overview CTR Impact Study. Industry Report, Feb 2026.
5. S. Feuerriegel et al. Understanding the Impact of SERP Features on Search Behavior. In Proc. SIGIR, 2023.
6. D. Lewandowski and S. Schultheiß. Public Awareness and Attitudes Towards Search Engine Optimization. arXiv preprint arXiv:2204.10078, 2022.
7. P. Aggarwal, V. Murahari, T. Rajpurohit, A. Kalyan, K. Narasimhan, and A. Deshpande. GEO: Generative Engine Optimization. In Proc. KDD, 2024.
8. Y. Chen et al. CC-GSEO-Bench: A Benchmark for Generative Search Engine Optimization. Preprint, 2025.
9. P. Strauss et al. Do AI Search Engines Give Credit Where It's Due? Investigating the Attribution Crisis. Preprint, 2025.
10. E. Kirsten, J. Grosse Perdekamp, M. Upadhyay, K. P. Gummadi, and M. B. Zafar. Characterizing Web Search in the Age of Generative AI. arXiv preprint arXiv:2510.11560, 2025.
11. D. Pfrommer et al. Ranking Manipulation for Conversational Search Engines. In Proc. EMNLP, 2024.
12. M. Khalifa et al. Source-Aware Training Enables Knowledge Attribution in Language Models. Preprint, 2024.
13. L. Page, S. Brin, R. Motwani, and T. Winograd. The PageRank Citation Ranking: Bringing Order to the Web. Technical Report, Stanford, 1999.
14. P. N. Venkit et al. Search Engines in an AI Era: Understanding Challenges and Opportunities. In Proc. FAccT, 2025.
15. A. Kumar and L. Palkhouski. AI Answer Engine Citation Behavior: An Empirical Analysis of the GEO-16 Framework. arXiv preprint arXiv:2509.10762, 2025.
16. A. Bagga et al. E-GEO: Generative Engine Optimization for E-Commerce. Preprint, 2025.
17. N. Bardas, T. Mordo, O. Kurland, M. Tennenholtz, and G. Zur. White Hat Search Engine Optimization Using Large Language Models. arXiv preprint arXiv:2502.07315, 2025.
18. X. Chen, H. Wu, J. Bao, Z. Chen, Y. Liao, and H. Huang. RAID G-SEO: Role-Augmented Intent-Driven Generative Search Engine Optimization. arXiv preprint arXiv:2508.11158, 2025.
19. K. Ando and T. Harada. Aligning Large Language Model Behavior with Human Citation Preferences. arXiv preprint arXiv:2602.05205, 2026.
20. M. T. Ribeiro, T. Wu, C. Guestrin, and S. Singh. Beyond Accuracy: Behavioral Testing of NLP Models with CheckList. In Proc. ACL, 2020. (Best Paper Award)
21. T. Shin, Y. Razeghi, R. L. Logan IV, E. Wallace, and S. Singh. AutoPrompt: Eliciting Knowledge from Language Models with Automatically Generated Prompts. In Proc. EMNLP, 2020.
22. F. Huszár et al. Measuring the Performative Power of Search Engines. Preprint, 2024.
23. S. Aral, H. Li, and R. Zuo. The Rise of AI Search Engines: Implications for Information Markets and Human Judgement at Scale. arXiv preprint arXiv:2602.13415, 2026.
24. T.-Y. Liu. Learning to Rank for Information Retrieval. Foundations and Trends in IR, 2009.
25. Semrush. Query Length Statistics Across Search and AI Platforms. Industry Report, 2025.
26. M. Honnibal, I. Montani, S. Van Landeghem, and A. Boyd. spaCy: Industrial-Strength Natural Language Processing in Python. Zenodo, 2020. https://doi.org/10.5281/zenodo.1212303
27. Google. Search Quality Rater Guidelines: E-E-A-T Update. 2024.

Data and Code Availability

All data, prompts, scoring code, and per-brand results are available at github.com/keygrip/aeo-research. The repository includes the full brand corpus with aliases, prompt generation pipeline, scoring codebook (regex patterns, phrase lists, VADER/spaCy configuration), per-brand results across all sources, control prompt analysis, and keyword–brand alignment breakdowns.

Appendix A: Full Brand Corpus

Table 14 lists all 50 brands with aliases used for mention detection, primary domains for URL citation matching, and tier classification. Five fictitious brands (one per vertical) were verified non-existent via Google search on 2026-02-27: Wynthoral Financial, Grelvant Law, Plorantic Health, Jorvelle, and Velnith Market (356 scored responses, 0 mentions).

Table 14: Complete brand corpus with detection aliases and domains.

Aliases marked with * were configured in the scoring pipeline; unmarked aliases are known alternate forms not used in scoring (see §3.4, limitation 4).

†Healthcare has 2 midmarket and 4 startup brands due to the vertical's market structure; all other verticals follow the 4/3/3 split.

Appendix B: Scoring Codebook

The programmatic scoring pipeline produces 23 metrics across 8 signal categories. All scoring is deterministic (no API calls) and re-runnable. Full source code is available in the supplementary repository.

AIO preprocessing. Google AI Overview responses contain inline citation markers (e.g., "K Health +3") that are stripped via regex before scoring to prevent sentiment contamination.

Table 15: Complete scoring pipeline: 23 metrics across 8 categories.

Marginal association analysis. Marginal η² is computed as one-way ANOVA per factor: η²ₘₐᵣgᵢₙₐₗ = SSbetween / SStotal for each factor independently. Because the outcome is binary, η² from ANOVA is equivalent to R² from a linear probability model; we use this approximation for descriptive comparison. Because factors are hierarchically nested — keyword within brand, brand within vertical, tier as a property of brand — these marginal values overlap and do not sum to an additive partition. Additionally, keyword identity has 737 degrees of freedom (vs. 50 for brand, 5 for vertical); this mechanically increases its explanatory capacity and should be considered when comparing marginal η² across factors. The ~48% unexplained variance includes phrasing variation, factor interactions (keyword × intent, brand × source), and residual stochasticity. A supplementary BinomialBayesMixedGLM with keyword and brand as random effects confirms the qualitative ordering: keyword ICC = 34.4%, brand ICC = 23.0%, residual = 42.6% (logit-scale ICCs using the conventional π²/3 residual variance). Intent type is the strongest fixed effect (Cramér's V = 0.231).

Effect sizes. Chi-square tests use Cramér's V = √(χ²/(n·min(r−1, c−1))). Key results: vertical × mention (V = 0.120, small), tier × mention (V = 0.067, negligible), intent × mention (V = 0.231, small-to-medium for df*=4). Cohen's h for pairwise proportions: comparative (30.1%) vs. informational (7.5%) yields h = 0.607 (medium; computed from exact unrounded proportions).

Multiple comparisons. Bonferroni correction is applied within each family of pairwise comparisons (vertical: 10 pairs; intent: 10 pairs; source: 6 pairs; tier: 3 pairs; α_adjusted = 0.005 for 10-pair families). All five hypotheses are evaluated at α = 0.05 without cross-hypothesis correction, as they address substantively distinct questions. All reported results survive even a global Bonferroni threshold of α = 0.01.

Power. With N = 41,388 scored responses and baseline mention rate ~18%, the study detects 2pp differences at power > 0.99 and 1pp differences at power > 0.90. Underpowered for per-keyword comparisons where n < 20.

Non-independence. The 10 prompt variations per keyword are correlated paraphrases. Effective sample size is N = 750 keywords for headline statistics, not 20,408 responses. Within-keyword aggregation is used for all primary analyses. Chi-square p-values are reported at the response level; given the non-independence, these are anti-conservative (inflated significance). Cramér's V, which normalizes by N, is the primary effect-size measure; however, V remains influenced by non-independence in the underlying χ² statistic. Keyword-level chi-square tests yield qualitatively identical conclusions (see main text).

Appendix C: Statistical Details

Confidence intervals. All proportion estimates use Wilson score intervals at 95% confidence:

           p̂ + z²/(2n) ± z·√( p̂(1−p̂)/n + z²/(4n²) )
CI = ─────────────────────────────────────────────────
                      1 + z²/n

where z = 1.96. Wilson intervals are preferred over Wald intervals for proportions near 0 or 1, which is common in our data (~82% of keyword–brand pairs show 0% mention rate).

Download LaTeX PDF
